R14E-HL Spare Parts
| Key | Part Code | Description | Qty |
|---|---|---|---|
| 27/1 | RF-01 | Pump Cover | 1 |
| 27/10 | 16-02 | M6 Lock Washer | 8 |
| 27/100 | RB-67 | Valve Seat (1) | 1 |
| 27/101 | RB-66 | P-10A Back-up Ring (BC) | 2 |
| 27/102 | RB-68 | Release Valve | 1 |
| 27/103 | RB-69 | Release Valve Holder | 1 |
| 27/104 | RB-70 | P-6 O-Ring | 1 |
| 27/105 | RB-71 | P-6 Back-up Ring (EL) | 1 |
| 27/106 | RB-72 | Stopper Ring | 1 |
| 27/107 | RF-35 | Shaft | 1 |
| 27/108 | RB-74 | Spring (119) | 1 |
| 27/109 | RB-75 | Plug (1) | 1 |
| 27/11 | RF-06 | Main Base | 1 |
| 27/110 | RF-36 | Stopper Screw | 1 |
| 27/111 | 32A-01 | P-9 Back-up Ring (BC) | 1 |
| 27/112 | RF-38 | P-9 O-Ring | 1 |
| 27/113 | RF-39 | Valve Seat (2) | 1 |
| 27/114 | 16-36 | P-3 O-Ring (A) | 1 |
| 27/115 | RF-40 | Valve Stem | 1 |
| 27/116 | RF-41 | Washer | 1 |
| 27/117 | RF-42 | Spring (194) | 1 |
| 27/118 | RF-43 | Adjusting Screw | 1 |
| 27/119 | RB-84 | Lock Nut | 1 |
| 27/12 | RF-07 | M5 x 22 Screw | 8 |
| 27/120 | RF-44 | Valve Body | 1 |
| 27/121 | RB-87 | M6 x 12 Screw | 1 |
| 27/122 | RF-45 | Copper Gasket | 2 |
| 27/123 | RB-88 | Exhaust Pipe | 1 |
| 27/124 | RF-47 | Retainer | 1 |
| 27/125 | RF-48 | M4 x 4 Screw | 1 |
| 27/126 | RF-44G | Gasket (22) | 1 |
| 27/13 | RF-08 | Holder | 1 |
| 27/14 | RF-08G | Gasket (23) | 1 |
| 27/15 | RB-15 | M5 x 12 Screw | 3 |
| 27/16 | RF-09 | Nipple | 1 |
| 27/18 | RF-10 | Pump Ass'y | 1 |
| 27/19 | 32C-02 | M8 x 35 Screw | 4 |
| 27/2 | 410H-02 | M5 x 10 Screw | 5 |
| 27/20 | RF-11 | Oil Gauge | 1 |
| 27/21 | RF-12 | Oil Reservoir | 1 |
| 27/22 | EF-05 | Gasket (21) | 1 |
| 27/23 | RF-13 | Air Valve Ass'y | 1 |
| 27/24 | RB-09 | W-14 SI Seal Washer | 1 |
| 27/25 | RF-14C | Motor (230v) (240v) | 1 |
| 27/251 | RF-14 | Motor (Old Type) | 1 |
| 27/26 | RF-29A | Brush Holder (New Type) | 2 |
| 27/261 | RF-29 | Brush Holder (Old Type) | 2 |
| 27/27 | RF-15B | Brush (New Type) | 2 |
| 27/271 | RF-15 | Brush (Old Type) | 2 |
| 27/28 | RF-16B | Brush Cap (New Type) | 2 |
| 27/281 | RF-16 | Brush Cap (Old Type) | 2 |
| 27/29 | RF-18 | M4 x 6 Screw | 2 |
| 27/3 | 410-09 | M5 Lock Washer | 17 |
| 27/30 | RF-19 | Conduit Saddle | 1 |
| 27/31 | RF-17 | Switch Ass'y | 1 |
| 27/32 | RF-55A | Power Cord (230) (240v) | 1 |
| 27/33 | RA-25 | M4 x 8 Screw | 4 |
| 27/34 | RF-57 | Motor Plate | 1 |
| 27/35 | RF-110 | Toggle Switch | 1 |
| 27/36 | RA-19 | M4 x 8 Screw | 1 |
| 27/37 | 410-07 | M4 Lock Washer | 1 |
| 27/38 | RF-20B | Solenoid (230v) (240v) | 1 |
| 27/39 | RF-49 | M5 x 14 Screw | 4 |
| 27/4 | RF-02 | Wire Protection | 1 |
| 27/40 | RF-21 | Solenoid Valve Ass'y | 1 |
| 27/41 | RF-22 | Male Swivel Joint | 1 |
| 27/42 | 22-24 | P-16 Back-Up Ring (BC) | 2 |
| 27/43 | 22-25 | P-16 O-Ring (A ) | 2 |
| 27/44 | RF-24 | Female Swivel Joint | 1 |
| 27/45 | RF-23 | JG-16 Snap Ring | 1 |
| 27/46 | IB-04 | Adapter | 1 |
| 27/47 | EF-24A | High Pressure Hose (2M) | 1 |
| 27/48 | 410H-80 | Adapter 3/8" NPT-M. 3/8" PT-F | 1 |
| 27/49 | RD-12 | Male Coupler PH Type | 1 |
| 27/5 | RF-03 | Pressure Switch KPS700-1 | 1 |
| 27/56 | RB-30 | Key (1) | 1 |
| 27/57 | RB-31 | 6 x 6 Roller | 6 |
| 27/58 | RB-32 | Key (2) | 1 |
| 27/59 | RB-33 | Rotor | 1 |
| 27/6 | RF-04 | Copper Gasket (3) | 1 |
| 27/60 | RB-34 | Vane Cap | 1 |
| 27/61 | RB-35 | Drum | 1 |
| 27/62 | RB-36 | Bearing Plate AS-1106 | 2 |
| 27/63 | RB-18 | Suction Pipe | 1 |
| 27/64 | RF-25 | Strainer | 1 |
| 27/65 | RB-37 | Needle Thrust Bearing | 1 |
| 27/66 | RF-26 | Cam Ass'y | 1 |
| 27/67 | 26-22 | 1/4" Ball | 2 |
| 27/68 | RB-44 | Spring (70) | 2 |
| 27/69 | RB-45 | Piston | 3 |
| 27/7 | RB-03 | Switch Adapter | 1 |
| 27/70 | RB-46 | Cylinder | 1 |
| 27/71 | RB-47 | Check Valve (1) | 1 |
| 27/72 | 16-49 | 3/16" Ball | 6 |
| 27/73 | 16-48 | Spring (4) | 6 |
| 27/74 | RB-48 | Spring Holder | 6 |
| 27/76 | RB-53 | Low Pressure Pipe | 1 |
| 27/77 | 16-60 | P-7 O-Ring (A) | 4 |
| 27/78 | RB-49 | P-7 Back-up Ring (BC) | 2 |
| 27/79 | RF-27 | High Pressure Joint | 1 |
| 27/8 | RB-10 | OS17233 Oil Seal | 1 |
| 27/80 | RF-28 | Elbow Joint | 1 |
| 27/81 | RF-31 | Pipe | 1 |
| 27/82 | E3-68 | Copper Gasket (7) | 1 |
| 27/84 | RF-46 | Joint (2) | 1 |
| 27/85 | RF-32 | Base | 1 |
| 27/86 | RF-33 | 3 x 18 Drive Pin (AW) | 1 |
| 27/87 | RB-55 | PT 1/8" Screw | 2 |
| 27/88 | RB-57 | Spring Holder (1) | 1 |
| 27/9 | RF-05 | M6 x 20 Screw | 8 |
| 27/90 | RB-58 | Ball Holder | 1 |
| 27/91 | 16-26 | 7/32" Ball | 2 |
| 27/92 | 26-20 | Copper Gasket (4) | 1 |
| 27/93 | RB-60 | Stopper Screw | 1 |
| 27/94 | RB-61 | M6 x 40 Screw | 7 |
| 27/95 | RB-62 | M6 x 85 Screw | 4 |
| 27/96 | RB-63 | Plug (2) | 1 |
| 27/97 | RF-34 | Push Pin | 1 |
| 27/98 | RB-65 | P-10A O-Ring | 3 |
| 27/99 | 410-48 | P-4 O-Ring (A) | 1 |
