FP-700A Spare Parts
| Key | Part Code | Description | Qty |
|---|---|---|---|
| 1 | 100W-01 | M6 x 25 Screw | 2 |
| 10 | F700-03 | Foot Pedal Assembly | 1 |
| 11 | 700S-05 | Pump piston | 1 |
| 12 | 700S-06 | P-26 X-ring | 1 |
| 13 | 16-55 | P-26 O-Ring (A) | 1 |
| 14 | RB-66 | P-10A Back-up Ring (BC) | 1 |
| 15 | RB-65 | P-10A O-Ring | 1 |
| 16 | 700S-10 | M12 x 12 Screw (FP) | 2 |
| 17 | 700S-11 | 3/8" Ball | 2 |
| 18 | 700S-12 | Spring (134) | 2 |
| 19 | 16-40 | 9/32" Ball | 3 |
| 2 | 13S-02 | Spring (219) | 2 |
| 20 | 16-49 | 3/16" Ball | 2 |
| 21 | 410-36 | Bypass Cartridge | 1 |
| 22 | 410-71 | S-9 O-Ring | 1 |
| 23 | 700S-15 | P-8 O-Ring (B) | 1 |
| 24 | 16-41 | M10 x 10 Screw (FP) | 2 |
| 25 | 700S-17 | 5/6" Ball | 2 |
| 26 | 700S-18 | Spring (213) | 1 |
| 28 | 16-26 | 7/32" Ball | 1 |
| 29 | RD-16 | M5 x 5 Screw (CP) | 1 |
| 3 | F700-01 | Foot Plate | 2 |
| 30 | 700S-191 | Release Knob Assembly | 1 |
| 31 | RF-38 | P-9 O-Ring | 1 |
| 32 | 300-73 | M5 x 5 Screw | 1 |
| 33 | F700-04 | Body | 1 |
| 34 | 700S-22 | 1/4" Ball | 3 |
| 35 | 700S-23 | M8 x 8 Screw (FP) | 3 |
| 36 | 410-73 | Filter Screen | 1 |
| 37 | 410-74 | SI-20 Ring | 1 |
| 38 | 13S-30 | Spring Stop Screw | 2 |
| 39 | F700-06 | Base (F) | 1 |
| 4 | 16-01 | M6 Hex Nut | 4 |
| 40 | 700S-27 | P-40 O-Ring | 1 |
| 41 | F700-07 | Oil Reservoir (15) | 1 |
| 42 | 410-55 | Reservoir Cap | 1 |
| 43 | 85-41 | M6 x 6 Screw (CP) | 2 |
| 44 | F700-08 | Reservoir Cover Assembly | 1 |
| 45 | RF-05 | M6 x 20 Screw | 1 |
| 46 | F700-09 | Spring (324) | 1 |
| 47 | F700-10 | Support Stand | 1 |
| 48 | 700S-331 | End Cap | 1 |
| 49 | F700-11 | M4 x 10 Screw | 1 |
| 5 | E3-16 | M6 x 14 Screw | 9 |
| 50 | E3-101 | M4 Flat Washer | 1 |
| 51 | 13S-37 | Rubber Support | 1 |
| 52 | F700-12 | Base (B) | 1 |
| 53 | RF-05 | M6 x 20 Screw | 2 |
| 54 | F700-13 | M6 x 10 Screw | 1 |
| 55 | 100-24 | Female Coupler IZUMI | 1 |
| 6 | 16-02 | M6 Lock Washer | 12 |
| 7 | 40-16 | CE-10 Snap Ring | 2 |
| 8 | 700S-01 | Pin (50) | 1 |
| 9 | F700-02 | Pin (126) | 1 |
