S-20A Spare Parts
| Key | Part Code | Description | Qty |
|---|---|---|---|
| 1/01 | 16-03B | Shoulder Bolt | 4 |
| 1/02 | 20-04 | Main Head | 1 |
| 1/03 | 20-71 | Slide Pin | 1 |
| 1/04 | 85-37 | Spring (144) | 1 |
| 1/05 | 20-70 | Spacer | 1 |
| 1/06 | 20-02 | Head Shear | 1 |
| 1/07 | 16-02 | M6 Lock Washer | 4 |
| 1/08 | 16-01 | M6 Hex Nut | 4 |
| 1/09 | 16-09 | CE-8 Snap Ring | 4 |
| 1/10 | 16-10 | Pin (46) | 2 |
| 1/11 | 16-11 | Latch | 1 |
| 1/12 | 55A-11 | M5 x 10 Screw (DP) | 1 |
| 1/13 | 20A-01 | Body Head | 1 |
| 1/14 | 20-07 | Blade | 1 |
| 1/15 | 16-17 | Spring (75) | 1 |
| 1/16 | 16-19 | Blade Screw | 1 |
| 1/17 | 16-21 | Ram | 1 |
| 1/18 | 16-22 | P-29 Back-Up Ring (BC) | 1 |
| 1/19 | 16-23 | P-29 O-Ring (A) | 1 |
| 1/20 | 16-24 | Valve screw (3) | 1 |
| 1/21 | 16-25 | Spring (2) | 1 |
| 1/22 | 16-26 | 7/32" Ball | 2 |
| 1/23 | 16-36 | P-3 O-Ring (A) | 1 |
| 1/24 | 40A-03 | 2.5 x 10 Dowel Pin (D) | 2 |
| 1/25 | 16-35 | Release Valve Stem | 1 |
| 1/26 | 16-33 | E-3.2 Snap Ring | 1 |
| 1/27 | 20-08 | Release Lever | 1 |
| 1/28 | 20-09 | Release Lever Insulation | 1 |
| 1/29 | 16-37 | Spring (77) | 1 |
| 1/30 | 16-28 | E-2.5 Snap Ring | 2 |
| 1/31 | 16-27 | Pin (26) | 1 |
| 1/32 | 16-47 | Pump Piston | 1 |
| 1/33 | 40A-05 | VC8 Oil Seal | 1 |
| 1/34 | 85-33 | P-8 Back-Up Ring (BC) | 1 |
| 1/35 | 16-44 | PS-8 Pent Seal | 1 |
| 1/36 | 20A-02 | Body | 1 |
| 1/37 | 16-41 | M10 x 10 Screw (FP) | 1 |
| 1/38 | 16-40 | 9/32" Ball | 1 |
| 1/39 | 16-39 | Spring (76) | 1 |
| 1/40 | 16-38 | M3 Flat Washer | 1 |
| 1/41 | 16-29 | Pin (47) | 2 |
| 1/42 | 16-30 | CE-6 Snap Ring | 4 |
| 1/43 | 16-31 | Pump Handle | 1 |
| 1/44 | 20-10 | Pump Handle Grip | 1 |
| 1/45 | 16-48 | Spring (4) | 1 |
| 1/46 | 16-49 | 3/16" Ball | 1 |
| 1/47 | 16-50 | Copper Gasket (6) | 1 |
| 1/48 | 16-51 | Suction Valve Screw Ass'y | 1 |
| 1/49 | 85-51 | S-36 O-Ring | 1 |
| 1/50 | 16-55 | P-26 O-Ring (A) | 1 |
| 1/51 | 20A-03 | Oil Reservoir (4) | 1 |
| 1/52 | ROB-25 | Magnet | 1 |
| 1/53 | 410-55 | Reservoir Cap | 1 |
| 1/54 | 16-63 | Body Handle | 1 |
| 1/55 | 20-11 | Body Handle Grip | 1 |
