UC-6B Spare Parts
| Key | Part Code | Description | Qty |
|---|---|---|---|
| 64/1 | 6A-01 | Neoprene Head Cover (UC-6A) | 1 |
| 64/10 | 6A-07 | Side Jaw | 2 |
| 64/11 | UC-07 | Roller Bearing | 10 |
| 64/12 | UC-08 | Roller Retainer | 2 |
| 64/13 | UC-06 | Side Jaw Spring | 2 |
| 64/14 | 6A-08 | Slide Plate (1) | 2 |
| 64/15 | 6A-09 | Cam Yoke | 1 |
| 64/16 | 6A-10 | Tool Cover (B) | 1 |
| 64/17 | 4W-28 | 4 x 14 Dowel Pin (G) | 2 |
| 64/18 | UC-28 | P-6 Back-up Ring (BC) | 1 |
| 64/19 | RB-70 | P-6 O-Ring | 1 |
| 64/2 | EG-64 | M5 x 30 Screw | 2 |
| 64/20 | UC-12 | Retaining Screw | 1 |
| 64/21 | UC-13A | Cam Yoke Holder | 1 |
| 64/22 | UC-14 | 4 x 30 Drive Pin (AW) | 1 |
| 64/23 | 16-42 | M4 x 6 Screw (FP) | 2 |
| 64/24 | UC-44 | Spring (406) | 1 |
| 64/25 | UC-16 | Ram | 1 |
| 64/26 | UC-17 | Spring Ass'y | 1 |
| 64/27 | 40-49 | CE-7 Snap Ring | 2 |
| 64/28 | 85-55 | Pin (35) | 1 |
| 64/3 | E3-49 | M6 x 30 Screw | 3 |
| 64/30 | 85-58 | Bushing | 4 |
| 64/31 | 85-59 | Pump Handle Head | 1 |
| 64/32 | 38A-03 | 5 x 30 Dowel Pin (G) | 1 |
| 64/33 | 300-07 | Handle Head Insulation | 1 |
| 64/34 | 85-60 | Spring (146) | 1 |
| 64/35 | 85-61 | Push Pin | 1 |
| 64/36 | UC-18 | Pump Handle Ass'y (Yellow) | 1 |
| 64/37 | 410-31 | Pump Handle Grip (2) | 1 |
| 64/38 | 85-30 | Pump Piston | 1 |
| 64/39 | 85-31 | P-18 X-ring | 1 |
| 64/4 | 6A-02 | Tool Cover (A) | 1 |
| 64/40 | UC-19 | P-18 O-Ring (CP) | 1 |
| 64/41 | 85-33 | P-8 Back-Up Ring (BC) | 1 |
| 64/42 | 16-44 | PS-8 Pent Seal | 1 |
| 64/43 | 85-35 | Release Valve Screw (7) | 1 |
| 64/44 | 410-35 | Release Valve Stem | 1 |
| 64/45 | UC-27 | P-3 O-Ring (CP) | 1 |
| 64/46 | 85-37 | Spring (144) | 1 |
| 64/47 | 410-36 | Bypass Cartridge | 1 |
| 64/48 | 410-71 | S-9 O-Ring | 1 |
| 64/49 | 410-43 | P-8 O-Ring (CP) | 1 |
| 64/5 | UC-03 | Fixed Jaw | 1 |
| 64/50 | 85-22 | P-34 Back-up Ring (BC) | 1 |
| 64/51 | 85-23 | P-34 O-Ring | 1 |
| 64/52 | 85A-08 | Valve Screw (12) | 2 |
| 64/53 | 16-48 | Spring (4) | 3 |
| 64/54 | 16-49 | 3/16" Ball | 3 |
| 64/55 | 85A-07 | Spring (164) | 1 |
| 64/56 | 40-20 | 1/8" Ball | 2 |
| 64/57 | UC-20 | Body | 1 |
| 64/58 | 410-46 | Suction Valve Plug | 1 |
| 64/59 | 410-47 | P-4 Back-Up Ring (BC) | 1 |
| 64/6 | 6A-03 | Pin (2) | 2 |
| 64/60 | 410-48A | P-4 O-Ring (CP) | 1 |
| 64/61 | 16-26 | 7/32" Ball | 3 |
| 64/62 | 85-47 | M4 x 4 Screw (FP) | 1 |
| 64/63 | 300-73 | M5 x 5 Screw | 1 |
| 64/64 | 410-51 | Spring Holder | 1 |
| 64/65 | 85-49 | Spring (43) | 2 |
| 64/66 | EG-52 | Copper Gasket (11) | 1 |
| 64/67 | UC-21 | Spring Holder | 1 |
| 64/68 | UC-22 | Spring (40) | 1 |
| 64/69 | UC-23 | Nipple | 1 |
| 64/7 | 6A-04 | Bushing | 2 |
| 64/70 | UC-45 | Packing | 1 |
| 64/71 | UC-24A | Cap | 1 |
| 64/72 | UC-40 | Cap Cover | 1 |
| 64/73 | C60-25 | S-40 O-Ring | 1 |
| 64/74 | 85-50 | Valve Screw (8) | 1 |
| 64/75 | 410-72A | Strainer | 1 |
| 64/76 | 410-73 | Filter Screen | 1 |
| 64/77 | 410-74 | SI-20 Ring | 1 |
| 64/78 | UC-25 | Body Insulation | 1 |
| 64/79 | 300-21 | P-28 O-Ring | 1 |
| 64/8 | 6A-11 | M3 x 8 Screw | 8 |
| 64/80 | 300-22 | Oil Reservoir | 1 |
| 64/81 | ROB-25 | Magnet | 1 |
| 64/82 | 410-55 | Reservoir Cap | 1 |
| 64/83 | UC-26 | Body Handle Ass'y (Yellow) | 1 |
| 64/84 | 300-26 | Body Handle Insulation | 1 |
| 64/85 | 300-27 | Body Handle Grip | 1 |
| 64/9 | 6A-06 | Slide Plate (2) | 2 |
