Spare Parts for CN-58A: Izumi Products.

CN-58A Spare Parts

Key	Part Code	Description	Qty
59/1	C58-01	Head	1
59/10	C58-05	Stroke Adjusting Nut	1
59/11	C58-06	SER-20 Scraper	1
59/12	C58-07	Spring (376)	1
59/13	C58-08	M4 x 5 Screw (FP)	2
59/14	C58-09	Ram	1
59/15	16-22	P-29 Back-Up Ring (BC)	1
59/16	16-23	P-29 O-Ring (A)	1
59/17	51-14	Pump Piston	1
59/18	40A-05	VC8 Oil Seal	1
59/19	85-33	P-8 Back-Up Ring (BC)	1
59/2	58-04	Collar	2
59/20	16-44	PS-8 Pent Seal	1
59/21	C58-10	Body	1
59/22	16-24	Valve screw (3)	1
59/23	16-25	Spring (2)	1
59/24	16-26	7/32" Ball	2
59/25	16-36	P-3 O-Ring (A)	1
59/26	51-15	Release Valve Stem	1
59/27	51-16	Release Lever	1
59/28	51-17	Spring (371)	1
59/29	51-18	Pin (129)	1
59/3	58-03	Spring (5)	2
59/30	51-35	CE-3 Snap Ring	2
59/31	51-36	Spring (343)	1
59/32	51-20	Spring (341)	1
59/33	410-48	P-4 O-Ring (A)	1
59/34	410-47	P-4 Back-Up Ring (BC)	1
59/35	51-21	Plug	1
59/36	16-30	CE-6 Snap Ring	4
59/37	51-23	Pin (131)	2
59/38	51-24	Pump Handle	1
59/39	51-25	Pump Handle Grip	1
59/4	58-02	Push Pin	4
59/40	5N-35	P-5 O-Ring (A)	1
59/41	51-26	Relief Valve Assembly	1
59/42	51-27	Spring (340)	1
59/43	16-49	3/16" Ball	1
59/44	100W-17	Copper Gasket (20)	1
59/45	51-28	Filter Assembly	1
59/46	16-55	P-26 O-Ring (A)	1
59/47	51-29	Oil Reservoir (16)	1
59/48	410-55	Reservoir Cap	1
59/49	85-51	S-36 O-Ring	1
59/5	58-01	Retaining Screw	4
59/50	51-37	Body Handle Assembly	1
59/51	51-31	Body Handle Grip	1
59/52	51-32	Band	1
59/6	C58-02	Die Retaining Screw	2
59/7	C58-03	D3 Saddle Dies	2
59/8	410-49	M5 x 8Screw	1
59/9	C58-04	Die Holder	1
